Asus
Asus Source Asus TUF Gaming 850W Gold [ID 34075]
Asus Source Asus TUF Gaming 850W Gold [ID 34075]
SKU:TUF-GAMING-850G
Description
Source Asus TUF Gaming 850W Gold Source Asus TUF Gaming 850W Gold Intel Form Factor ATX12V ATX 3.0 Yes Dimensions 150 x 150 x 86 mm Efficiency 80Plus Gold Protection Features OPP/OVP/UVP/SCP/OCP/OTP Hazardous Materials ROHS AC Input Range 100- 240Vac DC Output Voltage +3.3V +5V +12V -12V +5Vsb Maximum Load 25A 25A 70.8A 0.8A 3A Combined Load 130W 130W 850W 9.6W 15W Total Output 850W Connectors MB 24/20-pin x 1 CPU 4+4-pin x 2 PCI-E 16-pin x 1 PCI-E 8-pin x 3 SATA x 5 PERIPHERAL x 4 Package Contents Power Cord x 1 Motherboard Power Cable x 1 (610mm) CPU Cable x 2 (650mm) PCI-E Gen 5 16-pin Cable x 1 (675mm) PCI-E 1-to-1 Cable x 1 (675mm) PCI-E 1-to-2 Cable x 1 (675mm) SATA 1-to-2 Cable x 1 (400+120mm ) SATA 1-to-3 Cable x 1 (400+120+120mm) Peripheral 1-to-4 Cable x 1 (400+150+150+150mm) TUF Gaming Cable tie x 3 User Manual x 1 Weight 2.38kg (single PSU) 0dB Fan Button No
Available
| Quantity | Delivery |
| 10 | 2 days |
Couldn't load pickup availability
Description
Specifications
| Power | |
| Total power | 850 |
| AC input voltage | 100 - 240 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+3.3V) | 130 |
| Combined power (+12V) | 850 |
| Combined power (+5V) | 130 |
| Combined power (-12V) | 9.6 |
| Combined power (+5Vsb) | 15 |
| Max output current (+3.3V) | 25 |
| Max output current (+12V) | 70.8 |
| Max output current (+5V) | 25 |
| Max output current (-12V) | 0.8 |
| Max output current (+5Vsb) | 3 |
| Efficiency | 92 |
| Power protection features | Over current,Over power,Over voltage,Short circuit,Under voltage |
| Ports & interfaces | |
| Motherboard power connector | 24-pin ATX |
| Motherboard power cable length | 610 |
| Number of SATA power connectors | 5 |
| SATA power cable length | 120,400 |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| Peripheral (Molex) power cable length | 150,400 |
| EPS power connector (8-pin) | N |
| PCI Express power connectors (16-pin) | 1 |
| PCI Express power connectors (8-pin) | 3 |
| PCI Express power cable length | 675 |
| CPU power connector (4+4 pin) | Y |
| CPU power cable length | 650 |
| Cabling type | Fully-Modular |
| Performance | |
| Purpose | PC |
| Power supply unit (PSU) form factor | ATX |
| 80 PLUS certification | 80 PLUS Gold |
| ATX version | 3.0 |
| Bearing technology | Ball bearing |
| Mean time between failures (MTBF) | 170000 |
| Design | |
| Product colour | Black |
| Cooling type | Active |
| Fan diameter | 135 |
| Number of fans | 1 |
| Illumination | N |
| On/off switch | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 105 |
| Packaging content | |
| Cables included | AC,CPU,PCIe,Peripheral (Molex),SATA |
| Cable tie(s) included | Y |
| Weight & dimensions | |
| Width | 150 |
| Depth | 150 |
| Height | 86 |
| Weight | 2380 |
| Packaging data | |
| Package type | Box |
| Technical details | |
| Sustainability certificates | RoHS |
| Warranty period | 10 |
