Description
Specifications
Processor | |
Processor manufacturer | Intel |
Processor family | Intel Core i9 |
Processor generation | Intel Core i9-13xxx |
Processor model | i9-13900K |
Processor cores | 24 |
Processor socket | LGA 1700 |
Box | Y |
Cooler included | N |
Processor threads | 32 |
Processor operating modes | 64-bit |
Performance cores | 8 |
Efficient cores | 16 |
Processor boost frequency | 5.8 |
Performance-core boost frequency | 5.4 |
Performance-core base frequency | 3 |
Efficient-core boost frequency | 4.3 |
Efficient-core base frequency | 2.2 |
Processor cache | 36 |
Processor cache type | Smart Cache |
Processor base power | 125 |
Maximum turbo power | 253 |
Stepping | B0 |
Bus type | DMI4 |
Maximum number of DMI lanes | 8 |
Memory bandwidth supported by processor (max) | 89.6 |
Processor codename | Raptor Lake |
Processor ARK ID | 230496 |
Memory | |
Maximum internal memory supported by processor | 192 |
Memory types supported by processor | DDR4-SDRAM,DDR5-SDRAM |
Memory channels | Dual-channel |
ECC | Y |
Non-ECC | Y |
Memory bandwidth (max) | 89.6 |
Graphics | |
On-board graphics card | Y |
Discrete graphics card | N |
On-board graphics card model | Intel UHD Graphics 770 |
On-board graphics card outputs supported | Embedded DisplayPort (eDP) 1.4b,DisplayPort 1.4a,HDMI 2.1 |
On-board graphics card dynamic frequency (max) | 1650 |
On-board graphics card base frequency | 300 |
Number of displays supported (on-board graphics) | 4 |
On-board graphics card OpenGL version | 4.5 |
On-board graphics card DirectX version | 12.0 |
On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 5120 x 3200 |
On-board graphics card maximum resolution (HDMI) | 4096 x 2160 |
On-board graphics card maximum resolution (DisplayPort) | 7680 x 4320 |
On-board graphics card refresh rate at maximum resolution (HDMI) | 60 |
On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 |
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 120 |
On-board graphics card ID | 0xA780 |
Discrete graphics card model | Not available |
Number of execution units | 32 |
Multi-Format Codec Engines | 2 |
Features | |
Execute Disable Bit | Y |
Idle States | Y |
Thermal Monitoring Technologies | Y |
Market segment | Desktop |
Use conditions | PC/Client/Tablet,Workstation |
Maximum number of PCI Express lanes | 20 |
PCI Express slots version | 4.0,5.0 |
PCI Express configurations | 1x16+1x4,2x8+1x4 |
Supported instruction sets | SSE4.1,SSE4.2,AVX 2.0 |
Scalability | 1S |
CPU configuration (max) | 1 |
Direct Media Interface (DMI) Revision | 4.0 |
Embedded options available | N |
Export Control Classification Number (ECCN) | 5A992C |
Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
Processor special features | |
Enhanced Intel SpeedStep Technology | Y |
Intel® Speed Shift Technology | Y |
Intel® AES New Instructions (Intel® AES-NI) | Y |
Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
Intel® Turbo Boost Technology | 2.0 |
Intel® Quick Sync Video Technology | Y |
Intel® Clear Video HD Technology (Intel® CVT HD) | Y |
Intel Flex Memory Access | Y |
Intel Trusted Execution Technology | Y |
Intel® Thermal Velocity Boost | Y |
Intel® Adaptive Boost Technology | Y |
Intel® Turbo Boost Max Technology 3.0 frequency | 5.7 |
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Y |
Intel® Thermal Velocity Boost Frequency | 5.8 |
Intel® Control-flow Enforcement Technology (CET) | Y |
Intel® Thread Director | Y |
Intel® Standard Manageability (ISM) | Y |
Intel® Secure Key | Y |
Intel® Active Management Technology (Intel® AMT) | Y |
Intel Stable Image Platform Program (SIPP) | Y |
Intel® OS Guard | Y |
Intel 64 | Y |
Intel Virtualization Technology (VT-x) | Y |
Intel Virtualization Technology for Directed I/O (VT-d) | Y |
Intel Turbo Boost Max Technology 3.0 | Y |
Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Y |
Intel® One-Click Recovery | Y |
Intel® Stable IT Platform Program (SIPP) | Y |
Intel® Remote Platform Erase (RPE) | Y |
Intel® Virtualization Technology with Redirect Protection (VT-rp) | Y |
Intel® Boot Guard | Y |
Intel® Volume Management Device (VMD) | Y |
Mode-based Execute Control (MBE) | Y |
Intel® vPro™ Platform Eligibility | Y |
Intel VT-x with Extended Page Tables (EPT) | Y |
Intel® Total Memory Encryption - Multi Key | Y |
Intel® Hardware Shield Eligibility | Y |
Intel® Threat Detection Technology (TDT) | Y |
Intel vPro® Enterprise Platform Eligibility | Y |
Intel vPro® Essentials Platform Eligibility | Y |
Operational conditions | |
Tjunction | 100 |
Packaging data | |
Package type | Retail box |
Technical details | |
OpenCL version | 3.0 |
Target market | Gaming, Content Creation |
Launch date | Q4'22 |
Status | Launched |
Other features | |
L2 cache | 32768 |
Maximum internal memory | 192 |
Graphics output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
