nJoy UPS Aten PRO 1000, 1000VA/800W, On-line (double convention UPS), LCD Display, 3 [ID 29163]
nJoy UPS Aten PRO 1000, 1000VA/800W, On-line (double convention UPS), LCD Display, 3 [ID 29163]
SKU:PWUP-OL100AP-AZ01B
Description
UPS Aten PRO 1000, 1000VA/800W, On-line (double convention UPS), LCD Display, 3 Schuko Sockets with Protection, Tower, Smart SNMP & USB & RS-232, Efficiency up to 88%, Software management
Available
| Quantity | Delivery |
| 2 | 2 days |
| 1 | 3 days |
Couldn't load pickup availability
Description
Collapse
Specifications
Expand
| Features | |
| UPS topology | Double-conversion (Online) |
| Output power capacity | 1 |
| Output power | 900 |
| Waveform | Pure sine |
| Input operation voltage (min) | 120 |
| Input operation voltage (max) | 300 |
| Input frequency | 40 - 70 |
| Output operation voltage (min) | 200 |
| Output operation voltage (max) | 240 |
| Output frequency | 57/63 |
| Output voltage regulation | ±1 |
| Surge energy rating | 760 |
| Number of input phases | 1 |
| Number of output phases | 1 |
| Efficiency | 90 |
| Input power factor | 0.99 |
| Crest factor | 3:1 |
| ECO mode | Y |
| Total Harmonic Distortion (THD) (linear load) | 3 |
| Total Harmonic Distortion (THD) (non-linear load) | 6 |
| Noise level | 50 |
| Power protection features | Battery discharge,Over voltage,Overcharge,Overload,Short circuit,Surge protection |
| Audible alarm(s) | Y |
| Audible alarm modes | Fault,Low battery alarm,Overload alarm |
| Auto-restart | Y |
| Ports & interfaces | |
| AC outlet types | Type F |
| AC outlets quantity | 3 |
| USB port | Y |
| Serial interface | Y |
| Serial interface type | RS-232 |
| Serial ports quantity | 1 |
| Battery | |
| Battery voltage | 12 |
| Typical backup time at full load | 3 |
| Typical backup time at half load | 9 |
| Battery recharge time\t(90%) | 4 |
| Cold start | Y |
| Design | |
| Form factor | Tower |
| Product colour | Black |
| Cable length | 1.5 |
| Display type | LCD |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Operating relative humidity (H-H) | 20 - 90 |
| Packaging content | |
| Batteries included | Y |
| Technical details | |
| Warranty period | 2 |
| Weight & dimensions | |
| Width | 145 |
| Depth | 282 |
| Height | 220 |
| Weight | 9800 |
| Package width | 360 |
| Package depth | 230 |
| Package height | 325 |
| Package weight | 10500 |
| Package type | Box |
| Packaging data | |
| Cables included | Input power cable,USB cable |
| Manual | Y |
