TP-Link
TP-Link 8-port 10/100/1000 gigabit switch, PoE power supply [ID 25300]
TP-Link 8-port 10/100/1000 gigabit switch, PoE power supply [ID 25300]
SKU:TL-SG2008
Description
8-port 10/100/1000 gigabit switch, PoE power supply
Available
| Quantity | Delivery |
| 5 | 2 days |
Couldn't load pickup availability
Description
Specifications
| Management features | |
| Switch type | Managed |
| Switch layer | L2/L2+ |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| Cloud-managed | Y |
| ARP inspection | Y |
| System event log | Y |
| MIB support | Y |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Power connector | DC-in jack |
| Network | |
| Networking standards | IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x |
| 10G support | N |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
| Cable types supported | Cat3,Cat4,Cat5,Cat5e |
| Port mirroring | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Rate limiting | Y |
| Spanning tree protocol | Y |
| VLAN support | Y |
| Virtual LAN features | MAC address-based VLAN,Protocol-based VLAN,Tagged VLAN,Voice VLAN |
| Number of VLANs | 4000 |
| Data transmission | |
| MAC address table | 8000 |
| Switching capacity | 16 |
| Forwarding rate | 11.9 |
| Store-and-forward | Y |
| Static route | Y |
| Number of static routes | 32 |
| Number of IP interfaces | 16 |
| Jumbo frames support | Y |
| Jumbo frames | 9000 |
| Security | |
| DHCP features | DHCP client,DHCP relay,DHCP server,DHCP snooping,DHCPv6 client,DHCPv6 snooping |
| Access Control List (ACL) | Y |
| IGMP snooping | Y |
| IP-MAC-Port binding | Y |
| SSH/SSL support | Y |
| Security algorithms | SSH,SSH-2,SSL/TLS |
| BPDU filtering/protection | Y |
| Multicast features | |
| Multicast support | Y |
| Protocols | |
| Management protocols | SNMPv1/v2c/v3, SNTP |
| GARP VLAN Registration Protocol (GVRP) | Y |
| Design | |
| Product colour | Black |
| LED indicators | Y |
| Wall mountable | Y |
| Certification | CE, FCC, RoHS |
| Performance | |
| Internal memory | 256 |
| Flash memory | 32 |
| Fanless | Y |
| Power | |
| Power source | DC |
| Power supply included | Y |
| Input current | 1 |
| Input voltage | 12 |
| Power consumption (max) | 6.42 |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | N |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 |
| Storage temperature (T-T) | -40 - 70 |
| Operating relative humidity (H-H) | 10 - 90 |
| Storage relative humidity (H-H) | 5 - 90 |
| Weight & dimensions | |
| Width | 209 |
| Depth | 126 |
| Height | 26 |
| Packaging data | |
| Cables included | AC |
| User guide | Y |
